ABT Two-Beam Digital Infrared Beam Detector
红外光栅安装支架
ABT Two-Beam Digital Infrared Beam Detector
红外光栅安装支架
ABT Two-Beam Digital Infrared Beam Detector
Brand: Quan'an
Model: ABI-4
Features: Infrared light grid fence: warning distance from 5 to 100 meters, flexibly selectable per actual needs. Mainly used in community wall perimeter alarms, villa anti-theft alarm systems and other perimeter security fields! Compatible with mainstream alarm panels on the market.
  • Photos & Details
  • Specifications

Product name: two-beam digital infrared beam detector with one-touch lock bracket, easy to install

Model: ABT-30/60/100/150

Operating voltage: 12V-24V DC

Trigger time: 50-700ms

Installation position: various perimeter walls and main gates

Correction angle: horizontal 180° (±90°), vertical 20° (±10°)

Alarm mode: simultaneous interruption of two beams

Tamper output: contact output

Light source: infrared digital pulse

Operating temperature: -25°C to 55°C









With years of R&D and manufacturing in the alarm industry, we adhere to the principle of "product quality first, technology constantly updated" and have supplied quality security products to more than 4,000 engineering companies, earning unanimous praise from security users. If you need pulse electronic fences, tension electronic fences, vibration optical fiber cables, infrared beam/light grid detectors, home gas & smoke detectors and more...
Please contact us right away or call the hotline: +86-13590284141. We will answer all your questions in detail. Project Manager Online

Which alarm product do you need? Contact us now!

Antongruida · Founded in 2013 · Over a decade in security · Serving projects nationwide!
