The smart Tension Electronic Fence host can connect to the control rods at the front end of the fence via the 485 bus. The host has a built-in 4.3-inch display showing the zone ID, arm/disarm status, alarm status, time, temperature, various setting parameters (zone ID, arm/disarm status, alarm sensitivity, alarm output time, slack threshold, tension threshold) and other data (reference tension value, real-time tension value). With four built-in keys (function, cursor movement, increase, confirm) and the display, parameters such as zone ID, arm/disarm status, alarm sensitivity, alarm output time, the slack and tension thresholds of each tension line, and real-time time can be set intuitively. It has an RS485 communication interface for remote real-time control of the host, and can transmit alarm signals in real time to a remote control center for convenient centralized management. The host can automatically identify single-zone or dual-zone configuration, and each zone can be armed and disarmed independently. Each zone has an independent alarm output interface with diversified options (RS485 output, DC12V siren output, standard universal switch output), meeting different alarm output and linkage requirements. This Tension Electronic Fence host has built-in real-time acquisition, intelligent algorithm analysis and control system, which can effectively adapt to the front end, intelligently analyze and filter out environmental interference (wind, rain, falling leaves, thermal expansion and contraction due to ambient temperature, etc.), and reduce false alarms from non-effective events. It features accurate and timely alarms and extremely low false alarms.
1、控制杆外形尺寸：670*80*50mm
2、输入电压：DC12~24V
3、使用温度：-10~55℃
4、防区划分的距离应不大于40M
5、具有RS485总线通信功能
